SPECIFICATIONS

Depth Capability: 300feet(100 m)

Power requirement: 11 to 13V DC

Sonar Coverage: 45 degrees

Wireless operating range: 980 feet(300 m)

Wireless signal tower requirement: 11 to 13V DC1) Display: 3.5inch MVA-TFT-LCD

2) Back lighting: On/off White LED

3) Depth Capability: 328feet(100m)

4) Sonar Coverage:45degrees beam angle in 200Khz

5) Wireless operational Range: 980feet(300m)

6) Power Requirement: 11 to 13V DC

7) Water depth,water temperature, fish location, bottom contour can be constantly obtained from the water

8) User selectable sensitivity,zoom,units,depth range,shallow alarm,fish icon,fish alarm,and chart speed setting

9) Built in memory stores sonar setting when the fish finder is turned off

10) Operational Temperature: 14°F to 122°F(-10°C
to 50°C)
